| Insert Style: | CCGT |
|---|---|
| Corner Radius (mm): | 0.4 |
| Chipbreaker: | F1P |
| Grade: | IC908 |
| Material Application: | Steels; Stainless Steels |
| Maximum Depth of Cut (ap/mm): | 0.5 |
| Maximum Turning Feed (mm/rev): | 0.15 |
| Minimum Depth of Cut (ap/mm): | 0.1 |
| Minimum Turning Feed (mm/rev): | 0.05 |
| Application: | Finishing |
| ISO Code: | CCGT04T104 |
| Number of Edges: | 2 |
| Manufacturer Part Number: | 6837457 |
| Brand: | Iscar |
ISO-Turn – Single sided 80° positive rhombic turning insert with 2 cutting edges and a 7° clearance angle – A ground insert used for very low finish turning conditions of steel. Low cutting forces due to sharp ground cutting edge and a positive rake angle. Grade IC908 (PVD TiAlN coated) – A tough submicron grain size substrate with a PVD coating, recommended for general use for diverse operations on materials such as steels, alloy steels, austenitic stainless steel and high temperature alloys at a wide range of cutting speeds. Features high wear resistance and chipping durability.
Features & Benefits:
Iscar’s Iso-Turn – This is a wide range of Iso turning inserts that come in a variety of shapes, sizes, nose radius, chip breakers and grades. – Iso means these inserts can fit directly into any manufactures ISO external turning and internal holders. – There’s an insert configuration to machine any shape profile in all workpiece materials. Positive and negative inserts are available within this range.
