| Insert Style: | VCGT |
|---|---|
| Corner Radius (mm): | 0.1 |
| Chipbreaker: | AS |
| Grade: | IC20 |
| Material Application: | Non-Ferrous |
| Maximum Depth of Cut (ap/mm): | 2.5 |
| Maximum Turning Feed (mm/rev): | 0.2 |
| Minimum Depth of Cut (ap/mm): | 0.2 |
| Minimum Turning Feed (mm/rev): | 0.05 |
| Application: | Finishing/Medium |
| ISO Code: | VCGT160401 |
| Number of Edges: | 2 |
| Manufacturer Part Number: | 5507684 |
| Brand: | Iscar |
ISO-Turn – Single sided 35° positive rhombic turning insert with 2 cutting edges and a 7° clearance angle – positive flank, very positive rake angle and sharp cutting edge for machining aluminum. Grade IC20 (uncoated) – Used for finishing in aluminum, cast iron and stainless steel.
Features & Benefits:
Iscar’s Iso-Turn – This is a wide range of Iso turning inserts that come in a variety of shapes, sizes, nose radius, chip breakers and grades. – Iso means these inserts can fit directly into any manufactures ISO external turning and internal holders. – There’s an insert configuration to machine any shape profile in all workpiece materials. Positive and negative inserts are available within this range.
